    4 Needle Bar 16 Inch Multi Needle Chain Stitch Quilting Machine

    Ask Lasest Price
    Brand Name : Yuxing
    Model Number : YXN-94-4D
    Certification : CE, ISO9001
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 30 SETS/MONTH
    Delivery Time : 20 Days
    • Product Details
    • Company Profile

    4 Needle Bar 16 Inch Multi Needle Chain Stitch Quilting Machine

    4 Needle Bar Multi-Needle Chain Stitch Quilting Machine For 16 Inch Designs


    Specification:

    Model nameYXN-94-4D
    Dimension(L*W*H)5.0*1.65*2.0m
    Gross Weight4.8 tons
    Quilting width2.45m
    Needle bar space4 bars (2"+3"+3" )
    Quilting thickness8cm
    Main shaft rolling speed600-1200r/min
    Throughput10-250m/hour
    Needle type#21-- #24
    X-axis movement410mm
    Needle space25.4mm
    Stitch adjustable2-8mm
    Rated voltage(AC)380V/50HZ 220V/60HZ
    Power required7.5KW

    Function

    1. Adopt the advance process design and upgrade computer system.
    2. Needle bar and pressing block take the double rocker, avoid the materials be soiled by lube.
    3. Anti-vibration hopper and fabric feeding-in tension motor to adjust fabric tension for different kind fabric.
    4. High rigidity machine body, perfect protecting equipment and steady-going control system.
    5. X,Y motors are driven by servo system, and main motor takes servo motor too.
    6. Thread break dectector and auto stop system. Auto lift needle and adjust the speed by computer.
    7. Auto fauls tips for servo motor system and test signal of sensors, which is convenient to eliminate problems.
    8. 180degree and 360 degrees quilting, imitless multi-span, can make tack and jump patterns.
    9. Sready running, high speed, low noise, very thick material with precise quilting.
    10. Ringing notice and infrared system to protect operater from hurt.

    4 Needle Bar 16 Inch Multi Needle Chain Stitch Quilting Machine

    Scheme


    4 Needle Bar 16 Inch Multi Needle Chain Stitch Quilting Machine

    Designs

    4 Needle Bar 16 Inch Multi Needle Chain Stitch Quilting Machine4 Needle Bar 16 Inch Multi Needle Chain Stitch Quilting Machine
