High Precision Multineedle Quilting Machines For Pajamas 210CM
Width
Application for multineedle quilting machine
This 210cm width multi needle quilting machine is usually suggested
for pajamas, quilt, bed cover, etc.
Suitable thread:
Upper thread: 40S/2; 50S/2; 120D/2
Bottom thread: 40S/2; 50S/2
Feature
Fuselage and beam and foot are reinforced. More stably on running.
Adjust speed by computer 500r-1200r/min, set different stitch
length(2mm-8mm) from computer .
New upgraded computer system, compatible with embroidery file format(DST/DSB)
Pattern compensation function is an effective solution for looping
pattern with thick material.
Auto stop sensor detect thread condition, when thread broken,
machine automatically stop.
The automatic oil refueling function can make the machine maintenance easier and prolongs the
machine lfetime.
180 degree and 360 degree random quilting patterns, and limited
multi span for tack and jump designs.
Big power servo motor and heavier machine body, Faster machine
running, up to 1200r/min
Ringing notice and infrared system keep worker operation safety.
Guaranty and Installation:
1. Give extra free spare part when ship with the machine.
2. Offer manual, pattern book, installation video and step by step
instruction if meet problems.
3. If need field installation or repairing machine, client should
bear tickets, food, hotel and labor cost $150/day.
4. Within a year if part is broken, the supplier can replace part
for free. Damage resulting from buyer's wrong operation / actions
without supplier's guide / force majeure is not in the scope of the
warranty. (note bobbin case, bobbin, needles, lamp is not in the
scope of the warranty)
Specification:
Model name | YXS-82-2D |
(L*W*H): mm | 4425*1750*1700 |
Weight | 5.5 tons |
fabric width | maximum 2100mm |
Distance between needle rows | 76.2(3") |
Distance between needles | 25.4 |
X-axis travel | 254 |
Sewing thickness | ≤50 |
Stitch | 2-8 |
Expected output | 10-240m/h |
Applicable needle | #14,#16,#19 |
Main shaft speed | 500-1200rpm |
Voltage | 380V/50HZ, 220V/60HZ |
Total Power | 5500W |
