320cm Width Industiral Multi-Needle Quilting Sewing Machines With
Servo Motor
Description
The D series multi needle quilting sewing machine is our newest
model. It adopts imported servo motor; new upgrade computer system;
machine body and beam are reinforced; maximum speed can reach 1200rpm; output can reach maximum 195m/hour. Hundreds designs can be
chosen; compatitble to embroidery designs; when thread broken, machine auto stop. Automatic oil fueling device.
Specification:
| Product Name | D Series Computerized Lock Stitch Multi-needle Quilting Machine |
| Model No. | YXS-128-2D/3D |
| Size(L*W*H) | 5590*1750*1700 |
| Gross Weight | 6600KG |
| Quilting width | 3200mm |
| Needle bar space | 76.2(3") / 152.4(3"+3") |
| Thickness of quilting | ≤50mm |
| Work speed | 500-1200r/min |
| Speed of production | 10-240m/hour |
| Model of Needle | #16,#19 |
| X-axis movement | 254mm |
| Needle space | 25.4mm |
| Stitch length | 2-8mm |
| Rated voltage(AC) | 380V/50HZ,/220V/60HZ |
| Total Power | 7.5KW |
Functions:
1,Computerized speed governing , max.1200r/min.
2, Needle row driven by aluminum alloy needle bar frame structure.
Oil free, sturdy and durable.
3, Saddles and Rollers driven by Imported Servo drive equipment.
4, Saddles using quilting machine with high rigidity design. The
stand of fabric separate from saddles, effectively reduce the
operating load of motor.
5, Design compensation function solves the out of shape problem
when sewing thicker material.
6, Machine body and beam are reinforced.
7, 360 degree free quilting come with unlimited Multi-span quilting
independent patterns, and compatotble with embroidery file format
8, Automatic thread-break detection unit.
9, Infrared sensor make sure more safety operation.
10,The machine runs smoothly,low noise, high precision, low
thread-break rate and easy to operate.
Warranty
Warranty: 1 year.
1) During warranty, the machine parts(except consumable parts, like
needle, hook, looper, etc) can be replaced for free.
2) Computer can be sent back to repair. Under warranty, if computer
broken, it can be replaced for free, but first need to send
computer back for checking.
3) Consumable parts is not under warranty. We provide additional
consumable parts with machine for about one year to use. Pls refer
to packing list.
4) Offer life-time after service. Any time if machine has problem,
customer can tell us problem with photos and small video. We will
help to solve problem by online guide. If problem very serious, we
can send technician to customer's place as request. Customer need
to bear visa cost, round trip flight tickets, food and board, and
technician labor cost USD100/day.
Aplication and designs
