    2.5M Automatic Computerized Chain Stitch Quilting Machine

    Ask Lasest Price
    Brand Name : Yuxing
    Model Number : YXN-94-3D
    Certification : CE, ISO9001
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 20 SETS/MONTH
    Delivery Time : 15 Days
    • Product Details
    • Company Profile

    2.5M Automatic Computerized Chain Stitch Quilting Machine

    2.5 M Automatic Computerized Chain Stitch Mattress Making Quilting Machine


    Quilting Machines Function:

    1. Adopt the advanced process design.

    2. Needle bar and pressing block take the double rocker avoid the materials be soiled by lube.

    3. High rigidity machine body,perfect protecting equipment and steady-going control system.

    4. X,Y motors are driven by servo system, and principal axis takes frequency ports system.

    5. Testing the working state of all sensors and computer in real time.

    6. The auto-stop system when the bottom or upper thread broke by infrared. Auto lift needle and adjust the speed by computer.

    7. Auto faults tips for servo motor system and transducer,which is convenient to eliminate problems.

    8. 360°quilting and limitless multi-span and independent quilting.

    9. Steady running, high speed, low noise, very thick material with precise quilting.

    10. Have ringing notice when start machine.


    Specification:

    Product NameComputer Non-shuttle (chain stitch) Multi-needle Quilting Machine
    Model

    YXN-94-3D(3"+3")

    Size(L*W*H)5000*1650*2000mm
    Weight6500kg
    Quilting width2450mm
    Needle bar space76.2,76.2(3"+3")
    Quilting thickness80mm
    Rolling speed600-1200 r/min
    Output10-250 m/hour
    Needle type#21-#24
    X-axis movement410mm
    Needle space25.4mm
    Stitch2-8mm
    Rated voltage(AC)380V/50HZ,/220V/60HZ
    Power7.5KW

    Pattern Show
    2.5M Automatic Computerized Chain Stitch Quilting Machine2.5M Automatic Computerized Chain Stitch Quilting Machine
