240CM 3 Rows Computerised Multi Needle Quilting Machine For Bed
Linens
Application for computerised quilting machine
This quilting machine can be used for sewing fabric and padding
together with different designs. The finished product is like
jackets, pajamas, night gown; bed cover, bed sheet, quilt, blanket,
comforter, bedspread, pillow case; ushions, seat covers, gloves,
bags.
Other models available:
1) Based on different work width : 64", 82", 118", 128" .
2) Based on needle bar quantity: 3 needle row quilting machine and
2 needle row quilting machine both can be chosen.
3 needle row machine can make bigger size design, usually for home
textile factory. 2 needle row machine make small size design,
usually for garments factory.
3) Based on shuttle size: Each machine can make as 10# bobbin or 7#
bobbin.
10# bobbin load about 30m longer thread than 7# bobbin. So more
home textile factory choose #10, and for garment factory to pursue
more precise design, we suggest #7 bobbin.
Specification:
| Model number | YXS-96-2CS/3CS |
| Size(L*W*H): cm | 460*150*170 |
| Weight | 5 tons |
| Suitable fabric width | maximum 245cm |
| Distance between needle rows | 76.2(3") / 152.4(3"+3") |
| Distance between needles | 25.4 |
| X-axis maximum movement | 25.4cm |
| Padding thickness | ≤50 |
| Stitch | 2mm-8mm |
| Expected yield | 10-210m/h |
| Needle type | #14,#16,#19 |
| Main shaft speed | 500-1000rpm |
| Voltage | 380V/50HZ,
220V/60HZ |
| Power supply | 6500W |
Feature
- Machine body and foot are reinforced. More stably on running.
- Adjust speed by computer 500r-1000r/min, set different stitch
length(2mm-8mm) from computer .
- New upgraded computer system, compatible with embroidery file
format(DST/DSB)
- Pattern compensation function is an effective solution for looping
pattern with thick material.
- Auto stop sensor detect thread condition, when thread broken,
machine automatically stop.
- 180 degree and 360 degree random quilting patterns, and limited
multi span for tack and jump designs.
